Portable laser optical emission spectrometer for rapid, accurate elemental analysis of metals and alloys — no sample preparation required.
The QuantoLux QLX9 uses laser-induced optical emission spectroscopy (Laser-OES) to deliver fast, accurate elemental analysis of metals and alloys without any sample preparation. A brief laser pulse ablates a microscopic amount of material, and the resulting plasma emission is analyzed to determine elemental composition in seconds.
The QuantoLux QLX9 is a handheld laser optical emission spectrometer (Laser-OES) that brings laboratory-grade elemental analysis to the production floor, warehouse, and field. Unlike conventional arc-spark OES instruments, the QLX9 requires no conductive sample preparation — the laser pulse works directly on as-is metal surfaces, including oxidized, painted, or corroded samples after minimal surface brushing.
The pulsed Nd:YAG laser delivers a precise, focused pulse to the sample surface, vaporizing a microscopic spot (< 0.5 mm) and generating a short-lived plasma. The emitted light is captured by a CCD spectrometer array that simultaneously measures emission lines across the full UV-visible spectral range, enabling multi-element analysis including carbon — a critical limitation of handheld XRF analyzers.
Results are displayed on a 5" color touchscreen within 5 seconds, with automatic grade matching against a built-in library of over 1000 standard alloy grades. Wi-Fi connectivity enables real-time data transfer to quality management systems for full traceability.
| Technology | Laser-Induced Optical Emission Spectroscopy (Laser-OES) |
| Analysis Time | < 5 seconds per measurement |
| Elements | C, Si, Mn, P, S, Cr, Mo, Ni, Cu, Al, V, Ti, Nb, W, Co, Fe, and more |
| Detector | CCD spectrometer array |
| Laser | Pulsed Nd:YAG laser |
| Spot Size | < 0.5 mm diameter |
| Sample Prep | None required (as-is surface) |
| Grade Library | > 1000 standard alloy grades |
| Display | 5" color touchscreen |
| Interface | Wi-Fi, USB, Bluetooth |
| Battery | 8 hours continuous operation |
| Weight | < 2.5 kg (handheld) |
| Standards | ASTM E1086, EN 10027 |
